母板 Stratix 10 Stratix 10 SX SoC Development Kit






S10SOC

Stratix 10 SX SoC Development Kit

You can use this development kit to:

  • Evaluate Stratix 10 SoC device features and performance
  • Begin development of your hardware and software design
  • Use as a platform for target reference designs, OS/BSP, and tools


Hardware
  • Stratix 10 SX SoC Development Board
    • Review Table 1 for featured Stratix 10 device
  • One HiLo DDR4 memory card (4 GB)
  • One DDR4 SODIMM memory card (16GB dual rank)
  • Two HPS peripheral daughter cards (OOBE and NAND)
  • Two FMC loopback cards supporting transceiver, LVDS and single-ended I/Os
  • Two quad small-form-factor pluggable (QSFP28) and one SFP+ port
  • Two FMC+ low-pin count (LPC + 15 transceivers) connector
  • One SFP+ interface
  • PCIe x16 edge connector (via cable - not included)
  • AC adapter power cables
  • Ethernet and USB cables

Software1
  • Design examples
  • Board Update Portal design
  • Board Test System (BTS) design
  • Documentation
  • Stratix 10 SX SoC Development Kit User Guide
  • Board design files
  • Design software2
  • Quartus Prime software (required)
  • Nios® II processor (optional)
  • MegaCore® intellectual property (IP) library (optional)
  • Mentor Graphics® ModelSim®-Intel software (optional)

  1. Download and unzip Stratix 10 SoC Development Kit installer first. Install the Stratix 10 SoC Board Test System.
  2. A one-year license for Quartus® Prime design software is available upon purchase of the kit. License activation instructions and FAQs .
