母板 Arria 10 TR10a-LP QDRII+ Arria 10 FPGA Development Kit






TR10a-LPQ

TR10a-LP QDRII+ Arria 10 FPGA Development Kit



FPGA

  • Intel Arria 10 GX FPGA (10AX115N2F45E1SG)


FPGA Configuration

  • On-Board USB Blaster II for FPGA programming
  • 1Gbit CFI Flash for FPPx16 configuration


Memory

  • 5 Independent 550 MHz QDRII, 18-bits data bus and 72Mbit (up to 288Mbits) for each

            (DDR4 memory version are also available. Please contact Terasic sales team .)


Communication and Expansion

  • PCIe Low Profile form-factor
  • PCIe x16 edge connector (includes dual pcie gen3 x8 interfaces)
  • Allows ultra-low-latency, straight connections to 2 external 40G QSFP+ modules
  • UART to USB for board management
  • With 2x5 timing expansion header for 1pps or other high precision clock inputs


Others

  • User LED x4, Button x2, Switch x2
  • Fixed Frequency OSC and Programmable Clock Generator
  • Power monitor, Temperature monitor, Fan control.
